Made in USA
Printer Specifications
- Head Qty: 3-8pcs
- Resolution: Max 720 x 2400dpi
- Color: K / C / M / Y / LC / LM / W / V Optional
- Printing Size: 100 x 51 inches / 2540 x 1300mm
- Printing Thickness: 0-4 inches / 0-100mm
- Data Interface: USB
- PC: Windows 10 / Windows 11
- Printing Media: Glass, Ceramic, Metal, PVC Board, Acrylic, Wood, PU, Wallpaper etc.
- Ink Type: Eco-friendly UV-curable Ink
- Input Format: Adobe Postcript, Level 3, PDF, JPEG, TIFF, EPS, AI
- Curing: High-effect UV LED
- Printer Weight: 3,417 pounds / 1,550 KG
- Printer Size: 183 x 87 x 63 inches / 4650 x 2200 x 1600 mm
- Power: 6.5kw
- Power requirement: Single phase AC 208-240C+10%. 50/60Hz. 32A
- Environment: Independent, clean, low dust, less light, good ventilation workshop
- Temperature: 18°C – 30°C / 64°F – 86°F
- Humidity: 30% – 70% (no condensation)
- Ventilation: It is recommended to use an overhead exhaust fan 600 cfm
Printhead – Ricoh GEN5
- Draft Mode: 592sq ft/h / 55m2/h
- Production Mode: 366sq ft/h / 34m2/h
- Quality Mode: 280sq ft/h / 26m2/h
Printhead – Ricoh GEN6
- Draft Mode: 753sq ft/h / 70m2/h
- Production Mode: 484sq ft/h / 45m2/h
- Quality Mode: 377sq ft/h / 35m2/h
